SRS™ Z2 Stand-On 28hp 52″Cut Mower

$19,799.00

A COMBINATION OF SPEED, AGILITY AND HIGH QUALITY OF CUT

The Soft Ride Stand-On SRS™ Z2 raises the bar with our adjustable operator platform, which features suspension technology that optimizes operator comfort and increases productivity. The superior balance provides stability and maneuverability that exceeds expectations for traction and handling. The SRS™ Z2 is designed to allow for quick operator exit and re-entry. Need to walk away from the mower to move an obstacle or debris? The PTO will automatically disengage when the operator leaves the platform. Restarting the blades is just as easy. When the operator steps back onto the platform and reengages the PTO switch they can continue mowing.

SKU: 5902037 Category: Tags: ,
Compare

Suspension Platform

The suspension platform system is adjustable for a large range of weights and operating conditions, optimising operator comfort and increasing productivity.

Integrated Mowing Transmissions

Commercial Hydro-Gear® ZT-3800® transaxles are designed for high performance and are fully serviceable.

Fuel Tank

Generous 30 litre fuel tank is centrally located for consistent balance, and the fuel filler neck is conveniently located on the side for easy filling.

Height of Cut

Height of cut is easily changed from the operator compartment for no hassle curb climbing and trailer loading.

Speed Control Setting

The easy locking 3-position speed control setting is conveniently located and requires no tools to facilitate smooth operation in a wide range of conditions.

Thigh Pad

Ergonomically designed thigh pad provides superior operator comfort, especially on uneven terrain.

HP (Gross)

28
Fuel Type

Petrol
Condition

New
Engine Brand

Vanguard™ 810cc EFI with Oil Guard
Power Take Off (PTO)

Electric PTO clutch
Number of Cylinders

V-Twin
Starting

Electric
Fuel Capacity (L)

30
Deck Type

Fabricated 10-gauge rear discharge steel deck
Cutting Width (cm)

132 (52)
Cutting Height (cm)

3.81 – 12.7 (1.5 – 5)
Deck Construction

3,4 mm fabricated construction, double top deck, double reinforced side skirts, overlap welded corners
Deck Size

52
Spindles

Cast aluminium 133 mm; 25,4 mm shaft
Suspension

Adjustable suspension platform
Transmission

Hydro-Gear® ZT-3800® transaxles
Drive Axels (in)

2.9 (1.125) Tapered
Drive Tyres (in)

23 x 10.5-12
Caster Tyres (in)

13 x 5-6, Flat-free
Ground Speed - Fwd (km/h)

0 – 16.1
Ground Speed - Rev (km/h)

0 – 8.05
Overall Length (cm)

172
Dry Weight (kg)

425
Roll-over Protection System

N/A
Instrumentation

Hour meter, fuel level gauge
Controls

Integrated forward & reverse control levers with stability bar, Automatic PTO Restart
Parking Break / Safety Circuit

Internal transaxle brake / Operator presence in platform, Parking brake safety circuit for starting engine
Balance of Machine Warranty

4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months).
